The VM Pack Automatic Shrink Packaging Machine is designed for seamless integration into industrial production lines. Operating with polyethylene (PE) shrink film, this model features a space saving, ergonomic design ideal for modern manufacturing environments. The color touch screen operator panel offers a user friendly interface, allowing settings to be adjusted quickly and easily.
The automatic shrink packing machine is designed to make shrink film replacement quick and effortless. Product transfer within the shrink tunnel is carried out using silicone coated steel rollers. We offer customized models to accommodate products of various sizes and shapes.
For detailed technical information, model selection, or pricing inquiries, please contact us.
Shrink film appropriate to the product dimensions is loaded into the film carriage of the machine.
Products are fed consistently into the machine via the feeding conveyor.
The products wrapped in shrink film are cut and sealed by a teflon coated hot sealing bar. They are then conveyed through a shrink tunnel. Inside the shrink tunnel, the controlled heat distribution allows the shrink film to tightly wrap around the product's surface and takes its shape. At the tunnel exit, cold air is applied to stabilize the packaging, ensuring a professional appearance.
| Feature | Description |
|---|---|
| Color Touch Screen Control Panel | User friendly interface allows for quick and easy adjustment of the machine settings. |
| Automatic Product Length Detection | Automatically detects product length for seamless packaging. |
| Product Counter | Counts the total number of packages produced during operation. |
| Motorized Film Unwinding | Automatically unwinds the shrink film from the roll during operation. Speed is adjustable via drive control. |
| Machine Material | The machine body is manufactured from steel construction and protected with electrostatic powder coating. |
| Warranty | 1-year warranty, with 5-year spare parts availability. |
| CE Compliance | The machine is equipped with mechanical and electrical safety measures in accordance with CE directives. |
| Max. Product Dimensions | Width: 500 mm, Length: 500, Height: 300 mm |
| Max. Speed | 12 packs/minute. |
| Packaging Material | Polyethylene (PE) shrink film 35–100 microns |
| Shrink Film Thickness | 35-100 micron |
| Max. Roll Width | 700mm |
| Air Pressure | 6 Bar |
| Voltage | 380V 50/60hz |
The Auto Shrink Wrap Machine is used for packaging various food products, as well as parquet, solid wood panel, timber, door, furniture, insulation materials, hose, cable, sandpaper, battery, electric heater, cooker, oven, and plastic kitchenware.
Packaging Solutions for Print, Education and Textile Products
Construction and Building Material Packaging
|
Home and Kitchen Appliance Packaging
Industrial Products and Spare Parts Packaging
Furniture and Structural Components Packaging
|
